PLUVIO
Tube type: Flexible hose with dripper
Dripper: Flat dripper with turbulent flows
Diameter (mm): 16-22
Thickness: from 6 to 18 mil
Flow rates (lt/h): 0.8 - 1.0 - 1.2 - 1.6 - 2.0 - 2.4 - 3.0 - 4.0
Working pressure (bar): 0.7 (max 1 bar)
Dripper spacing (cm): From 10 to 120
Dripper holes: 1
Minimum filtering (mesh): 130–150 mesh
See product
PLUVIO TAPE
Tube type: Flexible hose with continuous labyrinth
Dripper: Welded labyrinth (linear cut)
Diameter (mm): 16-22
Thickness: 5 to 10 mil
Flow rates (lt/h): 0.6 - 0.8 - 1.0 - 1.2 - 1.5 - 2.0
Working pressure (bar): 0.7 (max 1 bar)
Dripper spacing (cm): 10 to 40
Dripper holes: Self-closing linear cut
Minimum filtering (mesh): 130–150 mesh
See product
ATP TUBE
Tube type: Cylindrical PE tube with dripper
Dripper: Cylindrical dripper with turbulent flows
Diameter (mm): 16-20
Thickness: 1.1 mm (ø16), 1.3 mm (ø20)
Flow rates (lt/h): 1.6 - 2.0 - 4.0
Working pressure (bar): 1.5 (max 2 bar)
Dripper spacing (cm): From 20 to 100
Dripper holes: 2 (NORMAL) 4 (DOUBLE)
Minimum filtering (mesh): ≥130 mesh
See product
PC-DRIP ATP AS-DS TUBE
Tube type: PE cylindrical tube with dripper
Dripper: Turbulent flow dripper with membrane
Diameter (mm): 16-20
Thickness: 1.1 mm
Flow rates (lt/h): 2.0 - 4.0
Working pressure (bar): 1-3 bar (max 4 bar)
Dripper spacing (cm): From 20 to 100
Dripper holes: 2
Minimum filtration (mesh): ≥130 mesh
See product
